Description
fully automatic PLC GEAR HOBBING
- Make : PFAUTER
- Model : PA 210
- PLC control
- with PRISMATIC GUIDES (High precision and stability).
- with BALLSCREWS, easily convertible to full CNC machine.
- Max. workpiece diameter 220 mm
- Max. module : 6
- Max. axial slide travel 250 mm
- Min./max. teeth number (double-thread gear box) 4/60
- Max. cutter head angle +/- 40°
- Max. hob cutter
- diameter 163 mm
- length 230 mm
- Max. hob travel 170 mm
- Min./max. axle distance between work piece and tool 40mm/200 mm
- Indexing worm gear diameter 324 mm
- Diameter of worktable 240 mm
- Diameter of table bore 80 mm
- Diameter of cutter arbor 32 mm
