AUTOMATIC GEAR GRINDER, REISHAUER – NZA

Country

Here’s our AUTOMATIC GEAR GRINDING MACHINE (2 pieces)

It is in excellent working condition, for any information we are at your disposal.

SKU: automatic-gear-grinder-reishauer-nza Category: Tags: , , ,

Description

AUTOMATIC GEAR GRINDER

  • Make : REISHAUER
  • Model : NZA
  • machine equipped with FASSLER.
  • Max grinding diameter : 300 mm.
  • Min grinding diameter : 10 mm.
  • Gear width : 170 mm.
  • Module: Min : 0,5 / Max : 5.
  • Max clamping length : 420 mm.
  • Max angle of teeth : 45°.
  • Number of teeth : Min : 12 / Max : 130.
  • Slide stroke : 200 mm.
  • Helical lead : Min : 200 mm / Max : 6000 mm.
  • Max diameter of grinding wheel : 350 mm.
  • Max width of grinding wheel : 84 mm.
  • Total power requirement : 9 kW.
  • Dimensions : 2500x2000x2300 mm.
  • Total weight : 4600 kg
    THE MACHINE IS COMPLETE OF ALL CHANGE GEARS ETC..
